Loewe PLA 5303 PL - CRT Board

3 - 13
Gehäuse / Cabinet Art.-Nr. 87076.084/085
Pos.Nr. Bestell-Bezeichnung Bestell-Nr. Var.
Item N ° . Description List Part N ° . Var.
BAUGRUPPEN UNITS
U8211 Bedienteil kpl. Planus A2400 ................. Print Circuit Board ......................... 396-87777081
VERBINDUNGSLEITUNG .................................. CONNECTING CABLES
N8102 Netzkabel USA m. Drossel 3200lg ........ Power Cord ................................... 170-87684002
KNÖPFE BUTTONS
150 Knopf/Netzsch. schw. ............................ Button ............................................ 682-84569102
170 Knopf/Taster schwarz ......................... Button ............................................ 682-85081111
GEHÄUSETEILE CABINET MOUNTING
30 Träger / Bedien. schwarz ...................... Supporter ...................................... 541-87076702 084
30 Träger / Bedien. USA arktis .................. Supporter ...................................... 541-87076703 085
40 Klappe / Bedien. schwarz ..................... Cover Plate.................................... 706-86737002 084
40 Klappe / Bedien. hellgrau metallic......... Cover Plate.................................... 706-86737003 085
50 Klemmhalter für Bedienschublade ......... Holder............................................ 602-16603
60 Fenster/Infra .......................................... Window ......................................... 666-86736001
Bedienteil / Control Unit Art.-Nr. 87819.081
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
VERBINDUNGSLEITUNG CONNECTING CABLES
N8100 Netzverbindungskabel 1-pol.160lg. ....... Connecting Cable .......................... 171-87516001 081
SPULEN COILS
L8101 Relais 9VDC 350 Ohm .......................... Relay ............................................. 387-25050 081
T8101
Trafo USA 115V .................................... Power Transformer ........................ 490-27748 081
T8101 Trafo USA 115V/8V/1A mit Thermosich. Power Transformer ........................ 490-28963 081
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
H8006 Halter/Diode vorm. ................................ Holder............................................ 602-84535052 081
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
I8016 IR-Empfänger (1-Farbstreifen) ............ Coupler .......................................... 353-22155Y20 081
I8101 IC 78 L 05 ACP .................................. Integrated Circuit ........................... 349-15209020 081
BUCHSEN/FASSUNGEN SOCKETS
W8351 Kombibuchse ........................................ Socket ........................................... 323-28586 081
DIODEN DIODES
D8101 Gleichrichter B 40 C 800-R-A rund .... Rectifier ......................................... 354-27624040 081
D8206 LED 3mm rot Lowcurrent .................. Coupler .......................................... 353-22140 081
D8207 LED 3mm grün Lowcurrent ................. Coupler .......................................... 353-22141 081
SCHALTER SWITCHES
S8001 Taster (lang) ......................................... Switch............................................ 467-28135 081
S8002 Taster (lang) ......................................... Switch............................................ 467-28135 081
S8003 Taster (lang) ......................................... Switch............................................ 467-28135 081
S8101 Netzschalter 2-pol. TYP 8013EM....... Switch ............................................ 471-25599 081
Bedienteil / Control Unit Art.-Nr. 87819.081
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
WIDERSTÄNDE RESISTORS
R8301 10M J 0411 ...................................... Resistor ......................................... 367-27946Y05 081
R8302 10M J 0411 ...................................... Resistor ......................................... 367-27946Y05 081
SMD TEILE SMD PARTS
D8011 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8012 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8103 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8106 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8201 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8201 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8202 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8202 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8204 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8204 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8205 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8205 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8211 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8331 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8336 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8391 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8392 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8491 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8492 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
Q8002 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Q8111 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Q8114 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Bildrohrplatte / CRT Board Art.-Nr. 87833.053-055
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
SPULEN/LAUTSPRECHER COILS,SPEAKERS
L226 Dr. 2x 33U DK31 (931 112/13) .......... Choke ............................................ 298-24612
L366 Dr. 4U7 K LAL03VT/VB T.YUD. ......... Choke ............................................ 298-18104020
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
40 Montageclip 6mm .................................. Spring ............................................ 739-10230
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
I370 IC TDA6120N2 .................................... Integrated Circuit ........................... 349-27260
I380 IC TDA6120N2 .................................... Integrated Circuit ........................... 349-27260
I390 IC TDA6120N2 .................................... Integrated Circuit ........................... 349-27260
