Loewe PLA 5303 PL - Pla 5303; Basic Board

3 - 5
PLA 5303 Art.-Nr. 59470.00
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
G350 Ziergitter schwarz .............................. Speaker Grille ..............................708-87077012 L00
G350 Ziergitter arktis ..................................... Speaker Grille ................................ 708-87077013 U00
H1996 Abdeckung ............................................ Mask.............................................. 703-87883711
SPULEN/LAUTSPRECHER COILS,SPEAKERS
800 Lautsprecher 8 Ohm 11W .................... Loudspeaker.................................. 272-86074
810 Lautsprecher 8 Ohm 16 W ................... Loudspeaker.................................. 272-87474
820 Lautsprecher 8 Ohm Hochton............... Loudspeaker.................................. 272-85273
L6001 Entmagn. Spule 32/33" A2400 .............. Coil ................................................ 297-88037001
L6002 Spule Rotation ...................................... Coil ................................................ 297-26753
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
195 Clamper................................................. Cable Binding ................................ 530-21237
INTEGR.SCHALTUNGEN ................................... INTEGRATED CIRCUITS
I1891
ICMOS ST24E36F6 2400 Progr.A800 .. Integrated Circuit ........................... 349-90577800 00
VGA-EBS Art.-Nr. 87808.002
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
BAUGRUPPEN UNITS
10 LPL.VGA-/IR-Adapter A2400 kpl. ......... Print Circuit Board ......................... 396-87717060 002
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
30 Bolzen 4-40UNC KFS-4S-B1W ............. Bolt ................................................ 579-28642 87808002
Basic Board Art.-Nr. 87715.071/073/074
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
BAUGRUPPEN UNITS
30 Dyn. Focusblock (Focus/UG2).............. Scaffolding Access. ....................... 291-28956 071
30 Dyn. Focusblock (Focus/UG2).............. Scaffolding Access. ....................... 291-28956 074
R619 LPL. Degaussing Modul kpl. .................. Print Circuit Board ......................... 396-87862050
U0001 Dyn. Focusblock (Focus/UG2) ............. Scaffolding Access. ....................... 291-26627 071
U100 Tuner-ZF (USP) ................................... Tuner ............................................. 260-87507050 073
U202 Tuner-ZF USP99 ................................... Tuner ............................................. 260-87507051
U203 Tuner-ZF US ......................................... Tuner ............................................. 260-87346050
SPULEN COILS
L202 Dr. 47U K SMCC Fastron .................. Choke ............................................ 298-16925
L203 Dr. 4330 030 38100 VAL ..................... Choke ............................................ 298-14399
L534 Dr. 150U K ......................................... Choke ............................................ 298-79726020
L537 Dr. 200U ............................................... Choke ............................................ 297-23662
L538 Lin-Regler 4,6UH ................................. Deflection Unit ............................... 278-24475 071
L538 Lin-Regler .............................................. Deflection Unit ............................... 278-26787 074
Basic Board Art.-Nr. 87715.071/073/074
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
L538 Lin-Regler 5,4UH .............................. Deflection Unit .............................. 278-27544 073
L543 Dr. 572 05 018 00 Vogt ...................... Choke ............................................ 298-27471Y03
L553 Dr. 50U DR270/5 Kaschke ................ Choke ............................................ 298-22381 074
T528 Treiberspule Vogt 527.01.035.00 .......... Coil ................................................ 297-23664
T531
Zeilentrafo Q2300 ................................ Line Transformer ........................... 276-27373 071
T531 Zeilentrafo Q23/41/24/4140 ................... Line Transformer ........................... 276-27397 073
T531 Zeilentrafo ............................................. Line Transformer ........................... 276-28032 074
T540 Trafo AT 4043/67A ................................ Power Transformer ........................ 490-21351 071
T540 Trafo AT 4043/67A ................................ Power Transformer ........................ 490-21351 074
T612 Dr. 2x 10M 3,0A RK28 Plasma ............ Choke ............................................ 298-27507
T639
Trafo Wandler A2400 ............................ Power Transformer ........................ 490-28839 071
T639 Trafo Wandler A2400 33" ...................... Power Transformer ........................ 490-28841 073
T639 Trafo Wandler A2400 ............................ Power Transformer ........................ 490-29034 073
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
20 Aufsteckkühlkörper ................................ Screening ...................................... 509-27369
30 Linsenschraube AM 3 X10 Bruen ..... Screw ............................................ 432-74571
H474 Montageclip ........................................... Spring ............................................ 739-87529001
H484 Montageclip ........................................... Spring ............................................ 739-87529001
H509 Montageclip ........................................... Spring ............................................ 739-87529001
H534 Montageclip ........................................... Spring ............................................ 739-87529001
H539 Montageclip ........................................... Spring ............................................ 739-87529001
H560 Montageclip ........................................... Spring ............................................ 739-87529001
H561 Montageclip ........................................... Spring ............................................ 739-87529001
H562 Glimmerscheibe 16x21 .......................... Insulating Piece ............................. 421-10881
H586 Montageclip ........................................... Spring ............................................ 739-87529001
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
H587 Glimmerscheibe 16x21 .......................... Insulating Piece ............................. 421-10881
H611 Sicherungshalter für SI 5x20 ................ Fuseholder Spring ......................... 730-20061
H624 Montageclip ........................................... Spring ............................................ 739-87529001
H625 Glimmerscheibe 16x21 .......................... Insulating Piece ............................. 421-10881 073
H652 Montageclip ........................................... Spring ............................................ 739-87529001
H663 Montageclip ........................................... Spring ............................................ 739-87529001
H671 Montageclip ........................................... Spring ............................................ 739-87529001
H674 Montageclip ........................................... Spring ............................................ 739-87529001
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
10 IC L 7808 ACV .................................... Integrated Circuit ........................... 349-21780Y20
10 IC L 78S09CV geschnitten .................... Integrated Circuit ........................... 349-24013Y18
10 IC L 78 S 09 CV .................................. Integrated Circuit ........................... 349-24013Y22
I474 IC TDA 7296........................................ Integrated Circuit ........................... 349-28414
I484 IC TDA 7296........................................ Integrated Circuit ........................... 349-28414
I561 IC TDA8177......................................... Integrated Circuit ........................... 349-26528
I569 IC TL 431ACLP ................................... Integrated Circuit ........................... 349-19817020
I611
IC TDA4605-3/TDA4605 ..................... Integrated Circuit ........................... 349-22113
I663 IC L 7808ACV vormontiert ................... Integrated Circuit ........................... 349-21780050
I669
Opto-Koppler DIP4 80V 50/80 mA ..... Coupler.......................................... 353-28638
I670 IC TL 431ACLP ................................... Integrated Circuit ........................... 349-19817020
I674 IC TL 431ACLP ................................... Integrated Circuit ........................... 349-19817020
