Loewe PLA 5303 PL - Cal 2323; Aco 9303

3 - 3
CAL 2323 Art.-Nr. 59414.00
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
305 Clamper................................................. Cable Binding ................................ 530-21237
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
I1891 ICMOS ST24E36F6 A2400 Progr.A700.. Integrated Circuit ........................... 349-90577700 00
Klappe/Bed. vorm. / Cover Plate premounted Art.-Nr. 85748.081-082
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
KNÖPFE BUTTONS
30 Knopf III/Netzsch. sw. ............................ Button ............................................ 682-85877002
GEHÄUSETEILE CABINET MOUNTING
10 Klappe/Bedienung graphit ..................... Cover Plate.................................... 706-85748005 082
10 Klappe/Bedienung brillantsilber ............ Cover Plate.................................... 706-85748107 081
20 Magnet f. Klappe ................................. Magnet .......................................... 303-85893004
40 Druckfeder f. Knopf/Netzsch. ............... Compression Spring ...................... 726-85878001
50 Infrarot-Fenster für Bedienteil ................ Window ......................................... 666-84571101
60 Lagerbock (Scharnier) f. Klappe ............ Bearing Bracket ............................. 642-82773101
VGA-EBS Art.-Nr. 87808.002
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
BAUGRUPPEN UNITS
10 LPL.VGA-/IR-Adapter A2400 kpl. ......... Print Circuit Board ......................... 396-87717060 002
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
30 Bolzen 4-40UNC KFS-4S-B1W ............. Bolt ................................................ 579-28642 87808002
ACO 9303 Art.-Nr. 59471.00
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
BAUGRUPPEN UNITS
830 LPL. Frequenzweiche kpl. ..................... Print Circuit Board ......................... 396-85729063
970 VGA EBS A2400 ................................... Scaffolding Access ........................ 291-87808002
980 Adapter A2400 kpl. ................................ Print Circuit Board ......................... 396-87957050
U0004 Rotation-Panel Q2300 ........................... Print Circuit Board ......................... 396-87281051
U2400 BAS-B. kpl. A2400 TU-USP99,US/32" .. Print Circuit Board ......................... 396-87715074
U2401 SIG-B. kpl. A2400 .................................. Print Circuit Board ......................... 396-87934050
U3371 Bildrohrpl./SVM kpl. A2400 16:9 (RF) .... Print Circuit Board ......................... 396-87833055
U8211 Modul-Bedienung kpl. ACO A2400 ........ Print Circuit Board ......................... 396-87819081
DRUCKSACHEN OPERATING INSTRUCTIONS
500 BAN für USA-Geräte -GB- ..................... Operating Instruction ..................... 233-27832002
570 Garantie- und Antwortkarte USA ........... Guaranty Card ............................... 224-28352
580 Bed.-Kurzanleitung USA....................... Operating Instruction ..................... 233-28345002
GERÄTEBEIPACK SET SUPPLEMENT
A0640 Mikrozelle 1,5V Alkali-Mangan ............ Battery ........................................... 280-13411
N402 Subwoofer Adapter ................................ Socket ........................................... 323-86788
U0002 Adapter Antenne IEC-F männlich .......... Socket ........................................... 323-28138
U9111 IR-Fernbedienung Control USA arktis . Transmitter .................................... 263-87000063
VERPACKUNGSMATERIAL PACKING MATERIAL
102 Schutzstreifen 1600 x 1250 mm .......... Protective Packing ......................... 253-84666022
600 Faltschachtel USA ................................. Packing Case ................................ 245-87749702
610 Packschalen-Satz 32" ACO ................... Cushion-Set................................... 252-87742050
J0701 Schutzstreifen 350 x 190 mm(IR-G.) ... Protective Packing ......................... 253-84666004
VERBINDUNGSLEITUNG CONNECTING CABLES
N8102 Netzkabel USA m. Drossel 3200lg ........ Power Cord ................................... 170-87684002
KNÖPFE BUTTONS
320 Tastenset für Servicefunktionen schwarzButton ............................................ 682-87685121
350 Knopf/Netzschalter schwarz ................. Button ............................................ 682-86697002
GEHÄUSETEILE CABINET MOUNTING
101 EJOT-PT-Schraube 10,0x45 K100x45 Screw ............................................ 440-19149
103 Führungsschiene ................................... Guide............................................. 553-87855001
105 Gehäusefuss farblos ............................. Foot ............................................... 783-82251105
106 Stütze .................................................... Support .......................................... 551-87854001
113 EJOT-PT-Schraube 4,0x14 KB40x14 . Screw ............................................ 440-27773
114 Filzstreifen 0,5x5x340mm...................... Felt Strip ........................................ 414-28825
115 Klebestreifen f. Rückwand ................... Foam Plastics Ledge ..................... 411-20926
200 Distanzstück .......................................... Clutch Piece .................................. 503-24754
230 Halter/Entmagn. .................................... Holder............................................ 602-87243001
301 Spaxschraube 4x13 ............................... Screw ............................................ 443-18169
311 Magnet D 8x4 ..................................... Magnet .......................................... 303-28596
GEHÄUSETEILE CABINET MOUNTING
330 Ölsilikondämpfer.................................... Gear Wheel ................................... 616-28668
331 Schraube EJOT-PT 3,0x8 KB30x8 ..... Screw ............................................ 440-23640
710 32Z „PH“W76-ERF031X044 .................. Picture Tube .................................. 345-28611
741 Halter..................................................... Holder ............................................ 602-85997101
742 Ring ....................................................... Clutch Piece .................................. 503-85996101
