Loewe PLA 5303 PL - Page 53

3 - 6
Basic Board Art.-Nr. 87715.071/073/074
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
I676 IC TL 431ACLP Integrated Circuit 349-19817020
I691 IC L 78S09CV vormontiert .................. Integrated Circuit ........................... 349-24013050 073
I691 IC L 78S09CV vormontiert .................. Integrated Circuit ........................... 349-24013051
TRANSISTOREN TRANSISTORS
10 Powmos TO220FP NCH 600V 8A ......... Transistor ...................................... 346-22395
10 TO220FP PNP 80V 3A 24W ................ Transistor ...................................... 346-28633
10 2SC5302 NPN 1500V 10A 50W ............ Transistor ...................................... 346-28864
Q508 BD537 TO220A ................................... Transistor ...................................... 346-77764
Q511 BF422 TO92 ........................................ Transistor ...................................... 346-11562020
Q526 TO92 NPN 100V 2A 1W ....................... Transistor ...................................... 346-20796020
Q531 ZTX712 E-Line .................................... Transistor ...................................... 346-27659020
Q532 ZTX614 E-Line .................................... Transistor ...................................... 346-27660020
Q533 BF422 TO92 ........................................ Transistor ...................................... 346-11562020
Q534 2SC4542 vormontiert ........................... Transistor ...................................... 346-25708Y20 073
Q534 2SC5302 ............................................... Transistor ...................................... 346-28864Y20
Q562
Powmos TO220FP NCH 50V 10A 30W ... Transistor ...................................... 346-18528
Q582 BC556B ................................................. Transistor ...................................... 346-74967020
Q585 BC547B TO92 ..................................... Transistor ...................................... 346-74983020
Q586 BD537 TO220A ................................... Transistor ...................................... 346-77764
Q589 BC557B ................................................. Transistor ...................................... 346-74878020
Q593 BC557B ................................................. Transistor ...................................... 346-74878020
Q624 Powmos TO220FP NCH 600V 8A ......... Transistor ...................................... 346-22395 073
Q624 Powmos TO220 600V 8A geschn. ......... Transistor ...................................... 346-22395Y20
Q646 Powmos TO220FP NCH 50V 10A 30W Transistor ...................................... 346-18528 073
Q646 BUZ 71AF1 ........................................... Transistor ...................................... 346-18528Y22
Q648 BC547B TO92 ..................................... Transistor ...................................... 346-74983020
Q661 BC547B TO92 ..................................... Transistor ...................................... 346-74983020
Q663 Powmos TO220FP NCH 50V 10A 30W Transistor ...................................... 346-18528
Q674 Powmos TO220FP NCH 50V 10A 30W Transistor ...................................... 346-18528
Q681 BC557B ................................................. Transistor ...................................... 346-74878020
Q682 Silpow TO220FP PNP 80V 3A 24W ..... Transistor ...................................... 346-28633Y22 073
DIODEN DIODES
10 3,0A 40V DO27 Schottky .................. Diode ............................................. 352-12657
10 10A 200V ISOWATT220AC ................ Diode ............................................. 352-28625
10 10A 200V geschnitten .......................... Diode ............................................. 352-28625Y20
D206 ZD 30V0 2% ....................................... Diode ............................................. 352-15763
D474 1 N 4148 DO35 ..................................... Diode ............................................. 352-31818
D491 1 N 4148 DO35 ..................................... Diode ............................................. 352-31818
D526 1 N 4148 DO35 ..................................... Diode ............................................. 352-31818
D527 EU 02V0 ................................................ Diode ............................................. 352-20289
D531 1,0A 400V DO41 Fast-GP .................. Diode ............................................. 352-20685
D532 BYW 98 RM15 ..................................... Diode ............................................. 352-20535
D533 BA 157 .................................................. Diode ............................................. 352-44799
D539 ESC011M .............................................. Diode ............................................. 352-23667
D541 BA 157 .................................................. Diode ............................................. 352-44799
D546 BA 157 .................................................. Diode ............................................. 352-44799
D547 BA 159 .................................................. Diode ............................................. 352-49148
D548 1 N 4148 DO35 ..................................... Diode ............................................. 352-31818
Basic Board Art.-Nr. 87715.071/073/074
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
D549 ZD 30V0 2% .................................... Diode ........................................... 352-15763
D557 1,0A 400V DO41 Fast-GP .................. Diode ............................................. 352-20685
D558 1,0A 400V DO41 Fast-GP .................. Diode ............................................. 352-20685
D561 BA 157 .................................................. Diode ............................................. 352-44799
D584 ZD 30V0 2% ....................................... Diode ............................................. 352-15763
D589 BA 157 .................................................. Diode ............................................. 352-44799
D590 BA 157 .................................................. Diode ............................................. 352-44799
D613 Gleichrichter FBI5L1M1 900V/5A ........ Rectifier ......................................... 354-27910Y22
D622 BA 157 .................................................. Diode ............................................. 352-44799
D624 BYT 13-1000 RM15 ............................... Diode ............................................. 352-22712
D636 BA 157 .................................................. Diode ............................................. 352-44799
D647 3,0A 40V DO27 ................................... Diode ............................................. 352-12657Y10
D652 BYT08PI-1000 ....................................... Diode ............................................. 352-28613
D656 BYW 98 RM15..................................... Diode ............................................. 352-25838
D660 ZD 12V0 ............................................... Diode ............................................. 352-44202
D661 BYW 98 RM15..................................... Diode ............................................. 352-20535 073
D663 BYW80-200F vormontiert ...................... Diode ............................................. 352-28625050
D666 SD 103C Schottky-Diode ..................... Diode ............................................. 352-17741
D669 1 N 4148 DO35 ..................................... Diode ............................................. 352-31818
D670 ZD 30V0 2% ....................................... Diode ............................................. 352-15763
D671 STPS20L40CF geschnitten/gebogen .... Diode ............................................. 352-20296Y20
D672 ZD 3V9 DO35 5% 0,5W .................... Diode ............................................. 352-10526
D680 ZD ZPY 100......................................... Diode ............................................. 352-28686
D681 BA 157 .................................................. Diode ............................................. 352-44799
D686 BYW 98 RM15..................................... Diode ............................................. 352-25838
D687 BYW 98 RM15..................................... Diode ............................................. 352-25838
POTENTIOMETER POTENTIOMETERS
P662 1K 6mm Kohleschicht horizont. ........... Potentiometer ................................ 375-22863020
SICHERUNGEN .................................................. FUSES
F611 6000 mA F 125V 5x20 ........................... Fuse .............................................. 380-27938
F656
1250 mA T 250V 8x8 ............................. Fuse .............................................. 380-27943020
F661 4000 mA F 250V 8x8 ............................. Fuse .............................................. 380-28944020
F672 5000 mA T 250V 8x8 ............................. Fuse .............................................. 380-27940020
KONDENSATOREN CAPACITORS
10 470N J 100V R5 ................................. Capacitor ....................................... 359-28078020 071
10 470N J 100V R5 ................................. Capacitor ....................................... 359-28078020 074
C531 2N7 J1600V R15 ................................. Capacitor ....................................... 359-25292 071
C531
3N0 J1600V R15 ................................. Capacitor ....................................... 359-25293 073
C531 2N2 J1600V R15 ................................. Capacitor ....................................... 359-26835 074
C538 Elko 47µ M 250V R7,5 18,5x41,5 .... Electrolyt Capacitor ....................... 360-22941
C539 470P J 1600V RM15 ........................... Capacitor ....................................... 359-28273 073
C540 Elko 2µ2 M 350V R 5,0 10x16 ............. Electrolyt Capacitor ....................... 360-28102020
C541
9N1 H R22,5....................................... Capacitor ....................................... 359-26619 071
C541 7N5 H2000V R22,5 8,5x17x26,5 ......... Capacitor ....................................... 359-27603 073
C541 7N5 H2000V R22,5 8,5x17x26,5 ......... Capacitor ....................................... 359-27603 074
C542 600N J 250V R22,5 11x21x27 ............ Capacitor ....................................... 359-24450 073
C542 520N J 250V R22,5 11x21 ................. Capacitor ....................................... 359-25886 074
