Loewe PLA 5303 PL - Page 59

3 - 12
Bedienteil / Control Unit Art.-Nr. 87506.081
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
SCHALTER SWITCHES
S8001 Taster vertikal (kurz) ............................. Switch............................................ 467-17895 081
S8002 Taster vertikal (kurz) ............................. Switch............................................ 467-17895 081
S8003 Taster vertikal (kurz) ............................. Switch............................................ 467-17895 081
S8101 Netzschalter 2-pol.TYP 8013EM ......... Switch ............................................ 471-25599 081
WIDERSTÄNDE RESISTORS
R8105 10M J 0411........................................ Resistor ......................................... 367-27946Y05 081
R8301 10M J 0411........................................ Resistor ......................................... 367-27946Y05 081
SMD TEILE SMD PARTS
D8091 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8092 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8103 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8106 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8201 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8201 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8202 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8202 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8204 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8204 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8205 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8205 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8211 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8331 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8336 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8391 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8392 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8491 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8492 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
Q8002 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Q8111 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Q8114 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 091
Bedienteil / Control Unit Art.-Nr. 87777.081
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
VERBINDUNGSLEITUNG CONNECTING CABLES
N8100 Netzverbindungskabel 1-pol.160lg........ Connecting Cable .......................... 171-87516001 081
SPULEN COILS
L8101 Relais 9VDC 350 Ohm .......................... Relay ............................................. 387-25050 081
T8101 Trafo USA 115V .................................... Power Transformer ........................ 490-27748 081
T8101 Trafo USA 115V/8V/1A mit Thermosich. Power Transformer ........................ 490-28963 081
Bedienteil / Control Unit Art.-Nr. 87777.081
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
ALLGEM.MECHAN.TEILE COMMON MECHANICAL PARTS
H8006 Halter/Diode VORM. .............................. Holder ............................................ 602-84535055 081
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
I8016 IR-Empfänger (1-Farbsteifen) .............. Coupler .......................................... 353-22155Y20 081
I8101 IC 78 L 05 ACP ................................... Integrated Circuit ........................... 349-15209020 081
DIODEN DIODES
D8100 Gleichrichter B 40 C 800-R-A rund ...... Rectifier ......................................... 354-27624040 081
D8206 LED 3mm rot Lowcurrent .................. Coupler .......................................... 353-22140 081
D8207 LED 3mm grün Lowcurrent ................. Coupler .......................................... 353-22141 081
SCHALTER SWITCHES
S8001 Taster vertikal (kurz) ............................. Switch ............................................ 467-17895 081
S8002 Taster vertikal (kurz) ............................. Switch ............................................ 467-17895 081
S8003 Taster vertikal (kurz) ............................. Switch ............................................ 467-17895 081
S8101 Netzschalter 2-pol.TYP 8013EM ......... Switch ............................................ 471-25599 081
WIDERSTÄNDE RESISTORS
R8301 10M J 0411 ........................................ Resistor ......................................... 367-27946Y05 081
R8302 10M J 0411 ........................................ Resistor ......................................... 367-27946Y05 081
SMD TEILE SMD PARTS
D8091 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8092 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8103 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8106 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8201 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8201 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8202 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8202 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8204 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8204 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8205 Diode ZD 5V6 SOD80 ZMM C ITT .... Diode ............................................. 351-16758 081
D8205 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8211 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8331 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8336 Diode ZD 12V0 SOD80 0,5W .............. Diode ............................................. 351-17532 081
D8391 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8392 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8491 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
D8492 Diode 0,2A 75V SOD80 LL4148 ....... Diode ............................................. 351-15015 081
Q8002 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Q8111 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
Q8114 Transistor BC847B SOT23 .................. Transistor ...................................... 344-14974 081
