Loewe PLA 5303 PL - Page 58

3 - 11
Signal Board Art.-Nr. 87934.050
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
Q1036 Transistor BC847BW SOT323 ............ Transistor ..................................... 344-27272 050
Q1038 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1046 Transistor BC807-25 SOT23 ................. Transistor ...................................... 344-16064 050
Q1057 Transistor BC817-25W SOT323 ........... Transistor ...................................... 344-28405 050
Q1094 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1099 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1122 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1132 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1152 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1158 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1160 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1163 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1167 Transistor BC817-25W SOT323 ........... Transistor ...................................... 344-28405 050
Q1193 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1214 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1219 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1223 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1225 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1229 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1233 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1235 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1239 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1240 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1243 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1252 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1266 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1272 Transistor BC817-25W SOT323 ........... Transistor ...................................... 344-28405 050
Q1291 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1296 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1320 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1323 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1325 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1346 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1348 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1361 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1363 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1367 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1372 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1373 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1376 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1381 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1416 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1426 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1431 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1436 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1441 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1562 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1567 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Signal Board Art.-Nr. 87934.050
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
Q1573 Transistor BC857BW SOT323 ............. Transistor .....................................344-28404 050
Q1591 Transistor BF550 SOT23 ..................... Transistor ...................................... 344-23563 050
Q1673 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1682 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1752 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1758 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1760 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1763 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1766 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1771 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1791 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1796 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1847 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1857 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1866 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1875 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1896 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1961 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1963 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Q1966 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1967 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1968 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1991 Transistor BC857BW SOT323 .............. Transistor ...................................... 344-28404 050
Q1997 Transistor BC847BW SOT323.............. Transistor ...................................... 344-27272 050
Bedienteil / Control Unit Art.-Nr. 87506.081
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
SPULEN COILS
L8101 Relais 9VDC 350 Ohm .......................... Relay ............................................. 387-25050 081
T8101 Trafo USA 115V .................................... Power Transformer ........................ 490-27748 081
T8101
Trafo USA 115V/8V/1A mit Thermosich ... Power Transformer ........................ 490-28963 081
ALLGEM. MECHAN.TEILE COMMON MECHANICAL PARTS
H8006 Halter/Diode vorm. ................................ Holder............................................ 602-84535052 081
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
I8016 IR-Empfänger (1-Farbstreifen) ............. Coupler.......................................... 353-22155Y20 081
I8101 IC 78 L 05 ACP ................................... Integrated Circuit ........................... 349-15209020 081
BUCHSEN/FASSUNGEN SOCKETS
W8311 Chinch-Buchse rot ................................ Socket ........................................... 323-17952 081
W8321 Chinch-Buchse weiss ........................... Socket ........................................... 323-17954 081
W8331 Mini-DIN-Buchse 4-pol .......................... Socket ........................................... 323-18108 081
W8401 Kopfhörerbuchse (Klinke) .................... Socket ........................................... 323-15966 081
DIODEN DIODES
D8100 Gleichrichter B 40 C 800-R-A rund ...... Rectifier ......................................... 354-27624040 081
D8206 LED 3mm rot Lowcurrent ................... Coupler .......................................... 353-22140 081
D8207 LED 3mm grün Lowcurrent ................. Coupler .......................................... 353-22141 081
