20
1. Channel (CH) number
2. Low battery indicator for CH sensor
3. Sensor signal strength icon
4. Indoor/CH sensor temperature trend
5. Water leak sensor status (for optional sensors)
6. Auto loop icon
7. Indoor/CH sensor temperature reading
8. Floating pool sensor icon
9. Soil moisture sensor icon
10. Indoor/CH sensor humidity reading
11. Indoor/CH sensor humidity trend
1 2
6 7 8 9 10 11
4 53
INDOOR/CHANNEL TEMPERATURE & HUMIDITY
INDOOR TEMPERATURE & HUMIDITY
This section can show the reading and status of the optional indoor hygro-thermo sensor(s)
and water leak sensor(s).
This section can show the reading and status of the temperature and humidity indoors.
