15
SETUP ZOOM
AUDIO SUBTITLE
MUTE REPEAT
SLOW DISPLAY
ANGLE
SOURCE
Power Supply
Mains Power
• This unit operates with a DC 9V 1.5A mains adapter (included).
• Connecting the unit to any other power source may damage to the unit. Unwind the
mains adapter to its full length. Connect the mains adapter to the DC IN 9-12V Socket
on the right side of the unit and then to a mains socket. Make sure the mains adapter is
fully inserted into the mains socket. The unit is now connected and ready to use.
• To switch the unit o completely, unplug the mains adapter from the mains socket.
AV IN
AV OUT ON OFF
DC IN 9-12V
DVD Player Right Side
To DC IN 9-12V Socket
To the Mains
Socket
Remote Control Operation Range
Point the remote control at the unit no more than 2 metres
from the remote control sensor and within a 40° arc of the front
of the unit. The operating distance may vary depending on the
brightness of the interior environment.
20° 20°
Within about 1.5 m
1 2
3
4
5
6 7 8
9 0
10+
REPEAT
TITLE
ENTER
MODE
SUBTITLE
AUDIO
MUTE
SOURCE
STEP
DISPLAY
MENU
VOL+VOL-
SLOW
ZOOM
• Turn o the unit before unplugging the mains adapter from the unit to avoid
damaging the unit.
• When the unit is not going to be used for a long period of time, disconnect the
mains adapter from the mains socket.
• The mains socket must be located near the unit and should be easily
accessible. If a malfunction occurs, disconnect the plug from the mains socket
at once.
• When the mains adapter is plugged in, the unit is not completely disconnected
from the mains power source, even when the unit is turned o.
L12SPDVD17_IB_Final171006V3.indd 15 9/10/2017 5:41 PM
