Logitek
1
Introduction
System Components
A base Artisan system is comprised of:
¾ 1 x
Artisan control surface
¾ 1 x
Artisan power supply (redundant)
¾ 1 x
Logitek Audio Engine
¾ 1 x PC running
Logitek application software w/RS-232 connection to Engine
The
Logitek Audio Engine is fitted with:
¾ 1 x
AE-C6 controller card (required)
¾ 2 x
SA-DSP processor cards (required)
¾ 2 x AE-PS power supplies (1 required – 2
nd
optional)
¾ Up to 8 I/O cards (as specified by customer)
o
IO-24A analog I/O cards (12 mono in / 12 mono out)
o
IO-8D digital I/O cards (8 AES in / 8 AES out)
o
NETA network card (1 per engine) – 500 channel fiber-optic network to share inputs
& outputs across multiple engines (optional)
Facilities running multiple
Artisan consoles can share audio between Engines, using the NETA
network card. Additional Engines can be added to expand I/O if required. An Artisan Audio Engine
can also share audio with
Audio Engines running Logitek’s radio surfaces.
Compatibility Matrix
Artisan is designed for use with Logitek Audio Engine 3.x or later. If running a facility with both
Logitek Artisan and radio consoles together, please note some cards require Artisan-specific
software.
Following is the minimum software release version/date that is required for
Artisan support.
Component General Support Additional Features
AE-C6 Controller Card Artisan-381 v3.91 -
SharcAttack DSP Artisan-380 v1.30 -
Supervisor v3 December 2006 -
CommandBuilder v3 December 2006 -
AEConfig v3 January 2007 -
vScreen v3 December 2006 -
vChange v3 December 2006 -
vSnapshot v3 December 2006 -
¬ See Appendix A for Artisan firmware release notes and version information.
Logitek Artisan Reference Manual
8
