Logitek
Appendix C
Pinouts
To Surface
Connection from Artisan PSU to Surface is via two 25-pair cables. Generally, there is no need to
make your own cables. However, the pinouts are shown for reference.
Surface A
Pin Connection Pin Connection
1 TX 1 26 +24V
2 RX 1 27 Ground
3 TX 2 28 +24V
4 RX 2 29 Ground
5 TX 3 30 +24V
6 RX 3 31 Ground
7 TX 4 32 +24V
8 RX 4 33 Ground
9 TX 5 34 +24V
10 RX 5 35 Ground
11 TX 6 36 +24V
12 RX 6 37 Ground
13 TX 7 38 +24V
14 RX 7 39 Ground
15 TX 8 40 +24V
16 RX 8 41 Ground
17 TX 9 42 +24V
18 RX 9 43 Ground
19 TX 10 44 +24V
20 RX 10 45 Ground
21 TX 11 46 +24V
22 RX 11 47 Ground
23 TX 12 48 +24V
24 RX 12 49 Ground
25 Cue Spkr - 50 Cue Spkr +
Surface B
Pin Connection Pin Connection
1 TX 13 26 +24V
2 RX 13 27 Ground
3 TX 14 28 +24V
4 RX 14 29 Ground
5 TX 15 30 +24V
6 RX 15 31 Ground
7 TX 16 32 +24V
8 RX 16 33 Ground
9 TX 17 34 +24V
10 RX 17 35 Ground
11 TX 18 36 +24V
12 RX 18 37 Ground
13 TX 19 38 +24V
14 RX 19 39 Ground
15 TX 20 40 +24V
16 RX 20 41 Ground
17 TX 21 42 +24V
18 RX 21 43 Ground
19 TX 22 44 +24V
20 RX 22 45 Ground
21 TX 23 46 +24V
22 RX 23 47 Ground
23 No connect 48 No connect
24 No connect 49 No connect
25 No connect 50 No connect
Logitek Artisan Reference Manual
52
