Appendix C
Pinouts
Appendix C Pinouts
To Audio Engine
Connection to the Audio Engine is via a RJ45 connector mounted on the rear of the Power Supply
Unit. When connecting to an AE-C6 Controller Card, straight through CAT5 cabling can be used.
Pin Connection
1 Cue -
2 Cue +
3 RS485 RX-
4 RS485 TX-
5 RS485 TX+
6 RS485 RX+
7 No connect
8 Ground
GPIs
GPI connections are on 25-pair Centronics Telco cables. We recommend terminating GPIs to Krone
style (or similar) termination blocks.
GPI Inputs
Pin Connection Pin Connection
1 GPI In 1 26 Ground
2 GPI In 2 27 Ground
3 GPI In 3 28 Ground
4 GPI In 4 29 Ground
5 GPI In 5 30 Ground
6 GPI In 6 31 Ground
7 GPI In 7 32 Ground
8 GPI In 8 33 Ground
9 GPI In 9 34 Ground
10 GPI In 10 35 Ground
11 GPI In 11 36 Ground
12 GPI In 12 37 Ground
13 GPI In 13 38 Ground
14 GPI In 14 39 Ground
15 GPI In 15 40 Ground
16 GPI In 16 41 Ground
17 GPI In 17 42 Ground
18 GPI In 18 43 Ground
19 GPI In 19 44 Ground
20 GPI In 20 45 Ground
21 GPI In 21 46 Ground
22 GPI In 22 47 Ground
23 GPI In 23 48 Ground
24 GPI In 24 49 Ground
25 GPI In 25 50 Ground
GPI Outputs
Pin Connection Pin Connection
1 GPI Out 1 26 GPI Out 1
2 GPI Out 2 27 GPI Out 2
3 GPI Out 3 28 GPI Out 3
4 GPI Out 4 29 GPI Out 4
5 GPI Out 5 30 GPI Out 5
6 GPI Out 6 31 GPI Out 6
7 GPI Out 7 32 GPI Out 7
8 GPI Out 8 33 GPI Out 8
9 GPI Out 9 34 GPI Out 9
10 GPI Out 10 35 GPI Out 10
11 GPI Out 11 36 GPI Out 11
12 GPI Out 12 37 GPI Out 12
13 GPI Out 13 38 GPI Out 13
14 GPI Out 14 39 GPI Out 14
15 GPI Out 15 40 GPI Out 15
16 GPI Out 16 41 GPI Out 16
17 GPI Out 17 42 GPI Out 17
18 GPI Out 18 43 GPI Out 18
19 GPI Out 19 44 GPI Out 19
20 GPI Out 20 45 GPI Out 20
21 GPI Out 21 46 GPI Out 21
22 GPI Out 22 47 GPI Out 22
23 GPI Out 23 48 GPI Out 23
24 GPI Out 24 49 GPI Out 24
25 GPI Out 25 50 GPI Out 25
