LONCIN LX700U-2 User Manual

88
3. If the oil is below the brim of the filler hole,
add sufficient oil of the recommended
type to raise it to the correct level.
NO-
TICE:
Be sure no foreign material enters
the final gear case.
4. Reinstall the oil filler bolt and its new
O-ring, and then tighten the bolt to the
specified torque.
Changing the final gear oil
1. Park the vehicle on a level surface.
2. Remove the final gear case guard by re-
moving the bolts and the collars.
3. Place an oil pan under the final gear case
to collect the used oil.
4. Remove the final gear oil filler bolt and its
O-ring, the final gear oil drain bolt and its
gasket to drain the oil.
5. Reinstall the drain bolt and its new gasket,
and then tighten the bolt to the specified
torque.
Tightening torque:
Final gear oil drain bolt:
20 Nm (2.0 m·kgf, 14 ft·lbf)

LONCIN LX700U-2 Specifications

General

Brand	LONCIN
Model	LX700U-2
Category	Utility Vehicle
Language	English
