LONCIN LX700U-2 User Manual

89
6. Refill with the recommended final gear oil
up to the brim of the filler hole.
NOTICE:
Be sure no foreign material enters the
final gear case.
7. Reinstall the oil filler bolt and its new
O-ring, and then tighten the bolt to the
specified torque.
8. Check for oil leakage. If oil leakage is found,
check for the cause.
9. Install the final gear case guard by installing
the bolts and the collars, and then tight-
ening the bolts to the specified torque.
Recommended oil:
SAE 80 API GL-4 Hypoid gear oil
Oil quantity:
0.23L
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
Tightening torque:
Final gear case guard bolt:
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
