Lonking CDM307 - Machine Qualification; Machine Congiguration

CHAPTER III MACHINE OPERATION
23
2.1 MACHINE QUALIFICATION
2.1.1 Labels are mounted on every machine to manage every machine
produced by the LONKING Holdings Limited.
They are at the different position of the machine. Here are description about the plates below.
2.1.2 APPRAISAL MARK AND THE IDENTIFICATION NUMBER OF THE
MACHINE
The appraisal mark sees the front position of the machine.
2.1.3 SERIAL NUMBER OF THE MACHINE
See the serial number on the right side of the machine.
2.1.4 APPRAISAL MARK OF THE ENGINE
Appraisal mark of the engine sees to the nameplate of the engine.
2.2 MACHINE CONGIGURATION
The machine has the following three different configurations:
1 ． CDM307 skid steer loader adopts Kubota V2403-T engine
The following table lists the basic parameters of Kubota V2403-T engine
Table 1
No. Project Parameter
1 Cylinder number-Inner diameter （ mm ）
4 － 87mm × 102.4mm
2 Seted power （ kW ）／ rotate speed （ rpm ）
42
／
2600rpm
3 Max. Torque （ N·m ）／ rotate speed （ rpm ）
165.1N·m ／ 1800rpm
4 Fuel consumption （ g ／ kW·h ）
270g ／ kW·h
5 Total displacement
2.434L
