Table 4
NO. Dimension Unit CDM307 CDM308 CDM312
A Max. Operating height
mm
3850
3850 3880
B Bucket pin height 2920
3050 3060
C Cab roof height 2020 2020 2050
D
Max. Height of horizontal
bucket
2730 2850 2870
E Length without attachments 2420 2530 2530
F
Length with standard
bucket
3340
3350 3350
G Max. Height unload angle ° 39
40 40
H Dumping height
mm
2180
2360 2440
J
Reach fully raised( for max.
dumping height )
790
610 610
K
Bucket on the ground
reversal angle
°
28 29 29
L
Bucket on tiptop reversal
angel
94 94 96
M Wheelbase mm 1050
1080 1080
P Ground clearance mm 210 210 180
Q Departure angle ° 27 27 28
R
Front turning radius without
attachments
mm
1200 1180 1180
S Front turning radius 2060 2050 2050
T Rear turning radius 1520
1580 1580
U Tail length 960 980 980
V Two wheel center distance 1240 1280 1320
W Bucket width 1528 1820 1820
