CHAPTER III MACHINE OPERATION
41
Direction Function
Front Left wheel forward
Rear Left wheel backward
Left Boom upper
Right Boom lower
3.2.6.2 The right control lever: the right joystick controls the right driving system and the bucket .its
position and the corresponding functions are shown in the following table.
Figure 17 RIGHT HANDLE OPERATION SCHEME
Direction Function
Front Right wheel forward
Rear Right wheel backward
Left Put bucket
Right Roll back bucket
