Operation Manual
10
Risk of explosion! Incorrect connection and jumper of
wires may lead to explosion and personal casualties.
Notice that the battery may be s tored at different
parts.
Fig. 3-8
Tips for air reservoir application (9)
Label location: beside the lifting eye of rear frame of overall unit
Always operate the machine as per the label;
otherwise, machine damage or personal injuries may
be caused.
日常保养时请打开储气
罐底部的放水开关，排出储
气罐内的油、水，避免因油
、水造成制动系统元器件的
早期损坏
Fig. 3-9
Fuel label (10)
Label location: near the round dipstick of right fuel tank in the forward direction of overall unit
Durin
routine maintenance,
please turn the drain switch a
bottom of ai
reservoi
to “ON
position to drain out the oil and
wate
in ai
reservoir, thus avoidin
earlie
dama
e of brakin
s
stem
elements due to oil and wate
left.
Tips for air reservoir application
