CDM816D WHEEL LOADER
28
V. Brakingsystem
1. Foot brake
Type Air booster caliper disc four wheel
brake
Brake disc diameter (mm) Φ410
Brake piston diameter (mm) Φ75(4 PCS)
Workingair pressure (Mpa) 0.7-0.78
Braking oil pressure (Mpa) 9.8MPa
Braking torque (N.m)/PCS 4300
2. Hand brake
Type Flexible-shaft controlled caliper disc
brake
Brake disc diameter (mm) 210
Brake pad dimension (mm) (length ×width ×thickness) 110×46×15
VI. Steering hydraulic system
Steering type Load-sensing full hydraulic steering
system
Steering gear BZZ1－315
Priority valve YXL-F160-N7 (160L/min)
Number of steering cylinders - bore × stroke (mm) 2—Φ63×280
VII. Working hydraulic system
Distribution valve ZL20DJL-02
Number of boom cylinders - bore x stroke (mm) 2-Φ90×607
Number of tilt cylinders - bore x stroke (mm) 1-Φ100×387
Gear pump
Type CBG2050
Rated speed (rpm) 2400
Flow (L/min) 120
System pressure (Mpa) 12
