CDM816D WHEEL LOADER
26
Wheel track 1400
Min. ground clearance 310
Max. dumping height (dumping distance ≥841) 2700
10. Steering angle (º) ±35
11. Operating weight (kg) 5500
III. Engine
1. Model: YT4A2-24
2. Type: In-line, water-cooled, direct injection
Number of cylinders - bore × stroke (mm) 4—105×120
Rated power (kW)/speed (rpm) 55/2400
Max. torque (N·m)/speed (rpm) 235/1680
Fuel consumption at rated condition (g/KW.h) 251.6
Fuel 0# or 10# light diesel oil
OD of exhaust fan (mm) Φ490
3. Air compr
essor
Rated speed (rpm) 1000
Actual displacement (m
3
/min) 0.1
4. Starter motor
Type QD2636A
Power (KW) 4.6
Voltage (V) 24
IV. Powertrain
1. Hydraulic torque converter
Type Single-stage three-element
Torque conversion ratio Ko 3.7
Cooling mode oil-cooling pressure circulation
Torque converter inlet oil pressure (Mpa) 0.50-0.60
