Operation Manual
27
Torque converter outlet oil pressure (Mpa) 0.20-0.30
Max. allowabletorque converter outlet temperature (℃)
120
Max. efficiency 0.82
2. Transmission
Type Fixed-shaft hydraulic shift
Gears Two forward gears and two reverse
gears
Gear ratio
Forward gear I 2.47
Forward gear II 0.88
Reverse gear I 2.52
Reverse gear II 0.898
Working oil pressure (Mpa) 1.2-1.5
Lubricating oil pressure (Mpa) 0.2-0.3
Transmission oil pump
Model CBG1025
Speed (rpm) 2400
Flow (L/min) 60
3. Main r
educer
Type Single-reduction with spiral bevel
gear
Reduction ratio 5.833:1
4. Hub reducer
Type Straight toothed s pur gear planetary
drive
Reduction ratio 4.4:1
5. Drive axle and wheel
Type FWD
Tyre 16/70-20
Tyre pressure (Mpa) 0.28-0.30
