Operation Manual
25
Chapter II Applications, Main Technical Performance and Parameters
I. Applications
CDM816D wheel loader is a multi-purpose construction m achinery mainly used for spad ing, loading
and transporting loose m aterials, applicable for the national defense, mine, water conservation,
infrastructure, freight yard, road construction, port and wharf, and c apable of loading, transportation,
bulldozing, excavating and lifting. Besides, it is a widely used and generally used construc
tion
machinery, which can undertake traction, leveling and piling, etc.
II. Overallperformance parameters
1. Rated bucket capacity (m³) 0.95
2. Rated load (t) 1.6
3. Boom lifting time (S) 4.9
4. Total cycle time (S) 9.4
5. Traveling speed (km/h)
Forward gear I 7.4
gearII 20.8
Reverse gearI 7.2
gearII 20.4
6. Max. breakout force (KN) 52
7. Max. grade ability (°) 30
8. Min. turning radius (mm)
Tyre center 4350
Outer side of bucket 5030
9. Physical dimensions (mm)
Vehicle length (with the bucket placed on the
ground flatwise) 5600
Vehicle width (outer side of wheel) 1800
Bucket width 1950
Vehicle height 2930
Wheelbase 2040
