16
5.5 Wiring of the sockets
5pin XLR (DMX):
Pin 1 = Ground, Pin 2 = DMX –, Pin 3 = DMX +
3pin XLR (analog):
Pin 1 = Ground, Pin 2 = 0-10 V + DC in, Pin 3 = 12 V + DC out, max. 50 mA
5.4.5.1 Auto start
If the timer is in operation and you disconnect the machine from the mains cable, the
Unique 2.1 will re-start in the Timer-Mode as soon as it‘s reconnected to the mains. To
stop this press the Mode-button [14] for more than 2 Seconds or by switching to „ESC“
in the Timer-Mode and then press the Enter-button.
5. Operating the Unique 2.1
With the internal timer, the haze time and wait time can be adjusted in Minutes
(0.1 - 99), the pump and fan output can be adjusted in per cent (0 - 99).
To start the Timer-Mode, press and hold the Mode button [16] for more than 2 Se-
conds. The red Timer/Profile-LED [19] will blink as soon as the machine has switched
to the Timer-Mode. As long as the timer is in operation, the red Timer/Profile-LED
blinks.
The adjusting of the output, haze time or wait time is the same as in the Standard-
Menu. This means you have to press the Mode button repeatedly until you reach the
required function.
With the Up/Down buttons you can adjust the required functions, then press the
Enter button to start the timer. Please note that P and F control Pump and Fan, whereas
P. and F. control Pause time and Haze (Fog) time (Figs. 10 - 13).
The timer cycle starts with the time shown on the display when you press the Enter
button (i. e. P.xx = Starts with wait time, F.xx = Starts with haze time). The timer cycle
will not start if you press the Enter button while the pump or fan output setting is
shown on the display.
You can switch back to the Standard-Menu by pressing the Mode button [14] for
more than 2 Seconds or by pressing the Mode button repeatedly until „ESC“ shows on
the display and then press the Enter button once.
