Lopi Answer - Chimney Termination & Air Intake

Stove Installation (for qualified installers only) 9
© Travis Industries 4/20/2020 - 1510 Answer
Clearances – Singlewall Connector
NOTE: Measure rear and side
stove clearances from the
nearest edge of the stove top.
NOTE: Measure front floor
protection from the face of the
stove (unibody).
23-5/8" (600mm)
16-1/4" (413mm)
5-7/8" (149mm)
19-1/2" (496mm)
16-1/2" (420mm)
US 6" (153mm)
Can. 8" (204mm)
27" (686mm)
US 16" (407mm)
Can. 18" (458mm)
FLOOR PROTECTION
18" (458mm)
US 6" (153mm)
Can. 8" (204mm)
19-1/2" (496mm)
23-5/8" (600mm)
16-1/4" (413mm)
5-7/8" (149mm)
US 6" (153mm)
Can. 8" (204mm)
US 16" (407mm)
Can. 18" (458mm)
FLOOR PROTECTION
10" (254mm)
ST
R
A
I
G
H
T
INST
A
LL
A
T
IONS
(singlewall connector)
CORNER INSTALLATIONS
(singlewall connector)
TOP OF STOVE
Connector
App. 6" (153mm) dia.
Approx. 42-1/4" (1074mm)
from Corner to Front
of Stove
US 6" (153mm)
Can. 8" (204mm)
TOP OF STOVE
Connector
App. 6" (153mm) dia.
IDB1164
