page 11
Picture pc-board BF11 (ControlPro power source)
X301
X201
X401
Overview changes front panels
Some front panels had been exchanged by versions with bigger memory.
Since week 51 from 2017 the version “Pulse” was added.
front panel designation
(old)
part no. designation
(new)
part no. version
pulse
part no. useage
FP01 BF05 653.0062.5 BF25 653.0083.5
wire feederBasic BF06 653.0048.5 BF26 653.0079.5
Basic Plus BF07 653.0049.5 BF27 653.0080.5 BF27 653.0107.5
Basic BF09 653.0051.5 BF29 653.0081.5
power source
Basic Plus BF10 653.0052.5 BF30 653.0082.5 BF30 653.0109.5
