Pc-Board DMRPP05
The pc-board DMRPP05 is the control unit for Push-Pull torches and the NanoFeeder.
In case of a Push-Pull application the DMRPP05 replaces the standard motor control pc-board DMR-RT3.
it consists of two pc-boards that are connected via at ribbon cables:
- pc-board DMRPP-P: power board containing the motor driver circuits
- pc-board DMRPP-C05: control logic
Functions
- driving and monitoring the normal wire feed motor as well as the Push-Pull motor
- driving the solenoid valve
- monitoring control elements (front panel, torch trigger switch)
LEDs
LED state designation
1 (red) o󰀨 DSP is ok
lit bright pc-board is in programming “ash” mode (DIP switch 1 is set to “ON”
lit weak DSP is not programmed
2 (green) on +5V supply voltage ok
o󰀨 +5V supply voltage is missing
3 (green) blinking DSP is working
lit continously wrong conguration (if DIP switch 2 ios set to “ON”
DIP switch
DIP switch setting function
1 ON programming mode active
OFF “normal” operation
2 ON conguration “intermediate feeder” (not supported by MicorMIG)
OFF conguration Push-Pull / NanoFeeder
