Connection Of Drain Hoses
Insertthedrainhoseintoadrainpipewithaminimumdiameterof4cm,orletitrun
intothesink,makingsuretoavoidbendingorcrimpingit.Theheightofdrainpipe
mustbelessthan1000mm.Thefreeendofthehosemustnotbeimmersedinwaterto
avoidthebackowofit.
PleasesecurelyxthedrainhoseineitherpositionAorpositionB
B
A

Backofdishwasher
MainsCable
WaterInlet
DrainPipe
Drainhose
Counter
How to drain excess water from hoses
Ifthesinkis1000higherfromtheoor,theexcesswaterinhosescannotbedrained
directlyintothesink.Itwillbenecessarytodrainexcesswaterfromhosesintoabowl
orsuitablecontainerthatisheldoutsideandlowerthanthesink.
Water outlet
Connectthewaterdrainhose.Thedrainhosemustbecorrectlyttedtoavoidwater
leaks.Ensurethatthewaterdrainhoseisnotkinkedorsquashed.
Extension hose
Ifyouneedadrainhoseextension,makesuretouseasimilardrainhose.
Itmustbenolongerthan4meters;otherwisethecleaningeectofthedishwasher
couldbereduced.
Syphon connection
Thewasteconnectionmustbeataheightlessthan100cm(maximum)fromthe
bottomofthedish.Thewaterdrainhoseshouldbexed.
