3
Wireless Camera
ENGLISH
3. Wireless Camera
1 2
4 5
3
1 Removable Antenna (SMA Type): Pre-attached to the back of camera.
2 Camera Stand
3 DC Power: Connect po
wer adapter to power on the camera.
4 Pairing Button: F
or details, see “Pairing Cameras” on page 8.
5 Antenna Jack
ATTENTION - This camera includes an Auto Mechanical IR Cut Filter. When the camera
changes between Day/Night viewing modes, an audible clicking noise may be heard
from the camera. This clicking is normal and indicates that the camera filter is working.
