Appendix A: System Specifications
ENGLISH
7. Appendix A: System Specifications
7.1 General Specifications
7.2 Receiver Specifications
7.3 Camera Specifications
TX Frequency Range 2.400GHz~2.480GHz
TX Power 16dBm
Unobstructed Effective Range 165ft (50m) indoor
500ft (152m) outdoor
1
1. Maximum wireless transmission range. Actual range dependent upon building materials and other obstructions in path of
wireless signal.
Data Rate 4 Mb/s
Modulation GFSK
Spread Spectrum FHSS
Operating Temperature Range 14°F ~ 122°F / -10°C ~ 40°C
RX Sensitivity -81dBm
Demodulation GFSK
Supported Resolution VGA (640x480) up to 25 frames per second
Termination 2x BNC video
Power Requirement 9V DC +/- 5%
Power Consumption 270mA Max
Dimensions (W x D x H) 53 x 137 x 86mm / 2.1 x 5.4 x 3.4" (with antenna attached)
Weight 0.1kg / 0.3lbs
Image Sensor Type 1/4" Color CMOS Image Sensor
Effective Pixels H: 640 V: 480
Image Compression MPEG4
Image Resolution VGA (640x480)
Lens 3.6mm F2.0
Field of View (Diagonal) 55°
AGC On
Power Requirement 9V DC +/- 5%
Power Consumption 430mA Max with IR LED
220mA Max without IR LED
Environmental Rating
1
1. Not intended for submersion in water. Installation in a sheltered area is recommended.
IP66
IR LED Quantity / Type 24 pieces / 850nm
Night Vision Range
2
2. Stated IR illumination ranges are based on ideal conditions in typical outdoor night time ambient lighting and in total
darkness. Actual range and image clarity depends on installation location, viewing area, and light reflection / absorption
level of object.
90ft (27m) / 135ft (41m)
Built in Auto IR Turn On / Off CdS Drive Auto IR LED turn On/Off Circuit
Dimensions (W x D x H) 79 x 203 x 117mm / 3.1 x 8.0 x 4.6" (with antenna and sun-
shade)
Weight 0.3kg / 0.6lbs
