LOUIS BIKER COAT/HELMET RACK SINGLE
1 | Scope of delivery
Fittings are listed in detail in the drawing (page6)
2 | General information
2.1 | Reading and keeping the instructions for use
These instructions for use apply solely to the Louis Biker Coat/Helmet Rack Single. They contain
important information on handling, safety and warranty. You should read these instructions carefully,
in particular the safety instructions, before using the Louis Biker Coat/Helmet Rack. Failure to
follow these instructions may cause damage to your helmet etc. Keep these instructions for future
reference. If you pass the Louis Coat/Helmet Rack to a third party, you must also hand over these
instructions.
The instructions for use are based on the standards and regulations applicable in the European
Union and reect the current state of technology. If abroad, you should also observe any country-
specic guidelines and laws.
1
Base plate
2
Arm section with hanger loops
3
Arm section without hanger loops
4
Helmet pad
5
3 wall plugs (8 x 40 mm)
6
3 countersunk head screws (5 x 50 mm)
7
3 M8 x 45 hex bolts
8
2 External toothed lock washer M8
9
2 Internal toothed lock washer M8
10
3 M8 spring washers
11
3 M8 lock nuts
12
6 M8 plastic caps
13
Instructions (not shown)
