Transducer installation | Installation Manual
Scout orientation
Attach the transducer to the scout bracket arm. Then install the
transducer and bracket arm to the bracket. Secure the assembly to
the motor using the hose clamp. The orientation can be adjusted
by rmly gripping and rotating the transducer until the alignment
marks are aligned.
