Terminal
Function
Note
15
Earth Ground
16, 17
Power Inputs
12-35 VDC or
12-24 VAC
± 10%
Table 3: Power Terminals for L-Switch XP 2-port LS-xxCB
Important: Do not ground the power supply wire on terminal 26 (LS-xxxxxCB) or terminal 17
(LS-xxCB) as shown in Figure 7!
LOYTEC recommends using its LPOW-2415B power supply with the L-Switch XP.
2.6 Connecting Diagrams
The L-Switch XP provides screw terminals to connect to the network as well as to the
power supply. The screw terminals can be used for wires having a maximum thickness of
1.5 mm
2
/AWG12.
2.6.1 LS-33CB (2-Port)
Terminal
Function
1
Earth Ground
2, 3
CEA-709 A, B of FT-10 Channel Port 2
4
Earth Ground
5, 6
CEA-709 A, B of FT-10 Channel Port 1
15
Earth Ground
16, 17
Power Supply
(do not connect terminal 17 to earth ground)
Table 4: L-Switch XP Terminals LS-33CB
