L-Switch User Manual 30 LOYTEC
Version 6.0 LOYTEC electronics GmbH
Table 1) is used to enable or disable the bit-rate auto-detection. If [2] Manual is selected the
setting made with Option 1 ā 5 is used to enable or disable the bit-rate auto-detection.
r - Router configuration
This menu item opens the CEA-709 router configuration menu as described in Section
5.3.5.
5.3.5 CEA-709 Router Configuration Menu
This menu allows configuring the CEA-709 router mode.
CEA-709 Router/Switch Menu
==========================
[1] Router mode : Smart Switch
[2] Subnet/node learning : subnet/node
[3] Group learning : enabled
[5] Block unknown domains : disabled
[6] Switch reset w. status button : enabled
[q] Quit without saving
[x] Exit and save
Please choose:
Figure 20 CEA-709 router configuration menu.
1 - Router Mode
The router mode menu allows setting the principal operating mode of the L-Switch XP
routing core. Normally the operating mode of the routing core is set with the DIP switches 1
and 2 but can be overridden in this menu.
Set router mode
===============
[1] Enable Configured Router Mode
[2] Enable Smart Switch Mode
[3] Set router configuration according to DIP switch
Please choose:
Figure 21 Router mode configuration menu
2 - Subnet/node learning
This menu option allows selecting the subnet/node learning mode (see Figure 22).
Set subnet/node learning mode
=============================
[1] Subnet/node learning
[2] Subnet learning
[3] Disable
[4] Set router configuration according to DIP switch
Please choose:
Figure 22 Selecting subnet/node learning mode
If subnet/node learning is selected the L-Switch XP will learn based on subnet/node
addresses (see Section 4.1.1.2). Subnet broadcasts are flooded. This mode is plug&play.
If subnet learning is selected the L-Switch XP will learn based on subnets. Subnet
broadcasts are only forwarded to ports, which contain nodes with that subnet. Subnet
learning should be enabled if group overloading is used in the case that more than 256
group addresses are needed. Subnet learning is not plug&play. Please use LonMaker, NL-
220, or other network management tools to ensure that one subnet address is only used
behind one L-Switch XP port. This can be achieved by using our L-Switch XP LonMaker
