Device Information
==================
Product: L-Switch XP
Product code: LS-13333CB
Firmware: L-Switch/L-IP Primary Image
Version: 6.0.0
Build date: Mon Sep 10 08:11:41 2012
Serial number: 007810-8000000951F4
Free memory: 11744K
Free flash: 6089K
RTEMS heap: 876K
CPU load: 0.0%
System temp: 33.0C
Supply volt: 23.8V
CEA-709 router unique node IDs
==============================
Port 1 : 80 00 00 09 51 F4 | 80 00 00 09 51 F9 (Online)
Port 2 : 80 00 00 09 51 F5 | 80 00 00 09 51 FA (Online)
Port 3 : 80 00 00 09 51 F6 | 80 00 00 09 51 FB (Online)
Port 4 : 80 00 00 09 51 F7 | 80 00 00 09 51 FC (Online)
Port 5 : 80 00 00 09 51 F8 | 80 00 00 09 51 FD (Online)
Figure 17: Device information
2 - Serial firmware upgrade
This menu item allows updating the L-Switch XP firmware via the serial interface (console).
See Section 7.2 for detailed instructions.
Note: If you select this option accidentally you can return to the main menu by sending a break
signal. In case your terminal program does not offer an option to send a break signal the
device has to be reset to return to the main menu.
3 - System configuration
Select this menu item to change system configuration settings. See Section 5.3.3 for details.
4 - CEA-709 configuration
Select this menu item to change the CEA-709 configuration settings. See Section 5.3.4 for
details.
8 - Reset configuration (factory defaults)
This menu item resets the L-Switch XP to factory defaults. See Section 5.5 for details on
how to load factory defaults by pressing the status button and Section 5.3.6 on how to load
factory defaults through the console menu.
0 - Reset device
This menu item resets the L-Switch XP.
5.3.3 System Configuration Menu
The system configuration menu allows setting basic device configuration options.
