LOYTEC CEA-709 - LS-13300 CB (3-Port); LS-33300 CB (3-Port)

L-Switch User Manual 15 LOYTEC
Version 6.0 LOYTEC electronics GmbH
2.6.4 LS-13300CB (3-Port)
Terminal
Function
1-6
NC
7
Earth Ground
8, 9
CEA-709 A, B of FT-10 Channel Port 3
10
Earth Ground
11, 12
CEA-709 A, B of FT-10 Channel Port 2
13
Earth Ground
14, 15
CEA-709 A, B of TP-1250 Channel Port 1
24
Earth Ground
25, 26
Power Supply
(do not connect terminal 26 to earth ground)
Table 7: L-Switch XP Terminals LS-13300CB
2.6.5 LS-33300CB (3-Port)
Terminal
Function
1-6
NC
7
Earth Ground
8, 9
CEA-709 A, B of FT-10 Channel Port 3
10
Earth Ground
11, 12
CEA-709 A, B of FT-10 Channel Port 2
13
Earth Ground
14, 15
CEA-709 A, B of FT-10 Channel Port 1
24
Earth Ground
25, 26
Power Supply
(do not connect terminal 26 to earth ground)
Table 8: L-Switch XP Terminals LS-33300CB
