Installation ProtoMat S

5.2 Unpacking the device

ATTENTION

Risk of injury!

The machine is heavy and bulky and cannot be transported or

lifted by one person!

Lift and transport the machine with two persons.

NOTE

The graphic unpacking instruction is to be found in the covering

box. After having removed the cover of the box you can take the

unpacking instruction and proceed as described.

■

Unpacking the circuit board plotter

1. Transport the euro pallet with a lift truck to the work desk.

2. Remove the adhesive tape from the box cover.

3. Lift the paper cover from the box.

4. Take the unpacking instruction and follow the instructions step by step.

♦ Now the circuit board plotter is unpacked and ready for installation.

Pos: 18 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_5_Inst allation_Inbetriebn ahme/5_3_Montage_u nd_Inbetriebnah me @ 0\mod_1254753952922_ 2058.docx @ 3643 @ 23443

5.3 Installation and commissioning

Note

Prerequisite for installation and start of operation is that the PC

and the dust extraction are available at the work place. PC and

dust extraction must be ready for operation.

Note

The control software CircuitPro has to be installed on the PC.

5.3.1 Installation

The installation of the circuit board plotter must be done in four steps:

I. Removal of the transport locks

II. Connection of the mains cable

III. Connection of the dust extraction
