10.1.1.2 HF and micro wave tool set 1/8“
Order code: 116 394
Tab. 18: HF-Tool
set 1/8“
Tool specification Length
(mm)
Ø
(mm)
Quan-
tity
End Mill RF, special tool, cylindrical, 1/8“ 36 0,15 3
End Mill RF, special tool, cylindrical, 1/8“ 36 0,25 5
End Mill RF, special tool, cylindrical, 1/8“ 36 0,40 3
End Mill long, cylindrical, PCB/aluminium 1/8“ 38 2,00 2
End Mill, cylindrical, PCB/aluminium, 1/8“ 36 1,00 5
End Mill, cylindrical, PCB/aluminium, 1/8“ 36 2,00 2
10.1.2 Consumables
10.1.2.1 Base material
Tab. 19: Base
material
Material Dimensions
(mm)
Copper
(µm)
Quan-
tity
Order
code.
Base material FR4 420 x 297 x 1,5 18/18 10 106 398
Base material FR4 420 x 297 x 1,5 -/35 10 106 400
Base material FR4 420 x 297 x 1,5 35/35 10 106 401
Base material FR4
with protective foil
420 x 297 x 1,5 5/5 10 112 059
Base material FR4
reference holes 3 mm
229 x 305 x 1,5 18/18 10 115 967
Base material FR4
reference holes 3 mm
229 x 305 x 1,5 -/18 10 115 968
Base material FR4
reference holes 3 mm
229 x 305 x 1,5 -/35 10 115 969
Base material FR4
reference holes 3 mm
229 x 305 x 1,5 35/35 10 115 970
Base material FR4
reference holes 3 mm and
protective foil
229 x 305 x 1,5 5/5 10 115 971
