LRS SCINTREX AUTOGRAV CG-6 User Manual

Getting started
CG-6 Operation Manual p/n 115370001 Rev A
2—4
Location of the CG-6 Autograv
TM
sensor
The following picture shows the location of the CG-6 Autograv
TM
sensor.
Figure 2-4 The CG-6 Autograv
TM
sensor location
Overview of the components
The following picture shows an overhead view of the all the components that are
supplied with a standard CG-6 Autograv
TM
in its transportation case.
Figure 2-5 The CG-6 Autograv
TM
and its components
Assembling the batteries
Because of stringent IATA regulations, the CG-6 Autograv
TM
batteries must be shipped
in individual packing, with a charge on no more than 30%. Before you can power up your
65.80 2.591
PROOF MASS POSITION
97.74 3.848
118.96 4.683
