④ Reference of implement installation part
19
(0.74)
A
B
CGHJLN
CAT.1
CAT.2
19.3
(0.75)
25.7
(1.01)
(Max.)
683
(26.8)
825
(32.4)
12
(0.47)
12
(0.47)
39
(1.53)
49
(1.92)
35
(1.53)
45
(1.77)
22.4
(0.88)
28.7
(1.12)
22
(0.86)
28
(1.10)
44.5
(1.75)
52
(2.04)
69
(2.71)
86
(3.38)
76
(2.99)
93
(3.66)
44
(1.73)
51
(2.00)
Unit : mm
(unit : inch)
D
(Min.)
E
(Max.)
F
(Min.)
K
25.4
(1.00)
①
Telescopic stabilizer
▶When adjusting the stabilizer’s length, set the lateral swinging clearance of the
implement to be 20~40mm. (0.8~1.6 in.)
Notice
③ Adjustment of stabilizer (optional)
- Telescopic type
 Pull up the link pin(1) and find a adaptable hole
with adjusting the stabilizer’s length.
 Insert the link pin(1) into the hole and let it
tightened firmly by locking spring.
