5 -56
1
3
2
③ Side light/Front turn signal light
bulb replacement - Cabin models
1. Remove the screw① retaining the turn signal
light lens and remove the lens.
2. Push in on the turn signal light bulb② and
rotate counterclockwise in the socket to remove
the old bulb.
3. Insert the new bulb into the socket and turn the
bulb in a clockwise direction until tightened.
4. If the side light bulb is damaged, open an
electrode terminal and pull out the bulb, and
replace it with a new one.
5. Install lenses and retaining screw①.
NOTE: For about bulb specification, refer to the
chapter 5-6-(4) in this manual.
