LS tractor XR4150

To Next Page

To Previous Page

2 -2

Instrument panel

Steering wheel

Driver’s

Seat

Sub step

Head lights

Cabin

Bonnet (Hood)

Front ballast weight

(optional)

Front axle

Fender

② Cabin type

Fuel tank
