34
IMFL20. BOOM GROUP
No.
LS PART NO.
DESCRIPTION
QTY
REMARKS
1-50
-
BOOM ASSY
1
1
40427413
COLUMN RH
1
2
40427414
COLUMN LH
1
3
40427415
BOOM
1
4
40427416
LINK BRACKET RH-OUT
2
5
40427417
LINK BRACKET RH-INN
2
6
40427418
BUCKET ROD
2
7
40427419
BOOM CYLINDER, Ø45xØ25x610LxST375
2
8
40427435
BUCKET CYLINDER, Ø40xØ25x565LxST350
2
9
40381823
PIN-LEVER, Ø25
2
10
40381822
LINK PIN, Ø6
2
11
40427443
CLAMP, 2.3t
2
12
40427444
CLAMP, 2.3t
2
13
40417727
SPRING WASHER, M6
4
14
40427445
BOLT, M6x20L
2
15
40431416
BOLT, M6x15L
2
16
40427447
STAND RH
1
17
40427448
BRACKET, 4t
1
18
40381532
BRACKET, 4t
2
19
40427449
STAND LH
1
20
40427450
BRACKET, 4t
1
21
40381815
PIN, Ø25
3
22
40381816
PIN, Ø25
1
23
40381818
PIN, Ø25
1
24
40427451
PIPE INSERT, Ø55x1x3
2
25
40381817
PIN, Ø25
3
26
40381819
PIN, Ø25
8
27
40381851
SHIM, 4t
4
28
40381845
SNAP RING, Ø25 Shaft
16
29
40427452
COVER, 2.3t
1
FL50CC0001~FL50CC0067
40431405
COVER, 2.3t
1
FL50CC0068~
30
40381862
PLAIN WASHER, M10
4
31
40381866
SPRING WASHER, M10
6
32
40381517
BOLT (10.9T), M10x25L
5
33
40381814
PIN, Ø20x48L
2
34
40381844
SNAP RING, Ø20
4
35
40381522
BOLT (10.9T), M12x90L
2
36
40381600
LOCK NUT, M12
2
37
40427453
BOLT (10.9T), M20x85L
2
38
40381802
LOCK NUT, M20
2
39
40381813
PIN, Ø16x80L
2
40
40381849
R-PIN, Ø3
2
