LS LL2300 - IMFL60. Boom Cylinder Group

39
IMFL50. HYDRAULIC LINE GROUP
No.
LS PART NO.
DESCRIPTION
QTY
REMARKS
1
40427464
PIPE
1
2
40427465
PIPE
1
3
40427466
PIPE
1
4
40427467
PIPE
1
5
40427468
PIPE
1
6
40427469
PIPE
1
7
40381599
T NIPPLE
4
8
40381598
ELBOW NIPPLE
2
9
40429517
NIPPLE, UNF 9/16”x4 – UNF 9/16”x2 (Ø1.1)
2
10
40427471
HOSE, 5/16”x1W/Bx850L(PT 3/8”x1 – CEL 10L) (RED, BLUE)
2
11
40427472
HOSE, 5/16”x1W/Bx900L(PT 3/8”x1 – DKOL 10L) (YELLOW, GREEN)
2
12
40393851
HOSE, 5/16”x1W/Bx440L (UNF 9/16”x4 – UNF 9/16”x4)
1
13
40427473
HOSE, 5/16”x1W/Bx425L (UNF 9/16”x904 – UNF 9/16”x4)
1
14
40426814
HOSE 5/16"x1W/Bx450L (CEL 10L - UNF 9/16"x4)
1
15
40427475
HOSE 5/16”x1W/Bx400L (CEL 10L – UNF 9/16”x4)
1
16
40427476
HOSE 5/16”x1W/Bx400L (UNF 9/16”x4 – UNF 9/16”x4)
4
17
40381841
Q-COUPLING, PT 3/8” (PIN) Female
4
