LS LL2300 - IMG980. Decal Group

46
IMFL91. OPTION 2(3
RD
FUNCTION KIT)
No.
LS PART
NO.
DESCRIPTION
QTY
REMARKS
1~34
40432044
3rd function kit(DI)-LL2300
1
1
40417720
3rd valve
1
2
40381841
Q-coupling, PT 3/8"(PIN)-Female
2
3
40435709
Plug-black, PT 3/8”
2
4
40417721
Elbow nipple, PT 3/8"x1-UNF 9/16"x4
2
5
40417722
Dowty washer, Ø17.28xØ23.8x2t
8
6
40417723
Nipple, PF3/8-UNF9/16(36)
3
7
40417724
Nipple, PF3/8-UNF9/16(54)
1
8
40417725
Benjo bolt, PF 3/8"
2
9
40381598
Elbow nipple, UNF 9/16"
4
10
40417749
T-nipple, UNF 9/16"x2-UNF 9/16"x2-UNF 9/16"x4
2
11
40417726
Plain washer, M6
4
12
40417727
Spring washer, M6
2
13
40417728
Nut, M6
2
14
40417729
Bolt, M6x50
2
15
40429270
3rd V/V cover
1
16
40428206
Lever assy
1
17
40417732
Hose clamp, 7/8"-6~22MM
1
18
40435636
Lever grip
1
19
40417735
Jam nut, M14x1.5Px8L
1
20
40435637
Switch with electronic cable, L=1500mm
1
21
40428207
Hose, 5/16"x1W/Bx390L(UNF 9/16"x904 - BENJO PF3/8")
1
22
40428208
Hose, 5/16"x1W/Bx430L(UNF 9/16"x904 - BENJO PF3/8")
1
23
40417753
Hose, 5/16"x1W/Bx370L(UNF 9/16"x904 - UNF 9/16"x904)
1
24
40417754
Hose, 5/16"x1W/Bx450L(UNF 9/16"x904 - UNF 9/16"x904)
1
25
40417739
2F housing
1
26
40417740
Slip on terminal(S), 0.35t x 19.5 x 21.2
2
27
40417741
2M housing
2
28
40417742
Slip on male terminal(S), 6.0 x 24.5 x 0.8
4
29
40421914
Electric cable, 2Cx0.75SQmm x 3000L
1
30
40417744
Electric cable, 1Cx0.75SQmm x 180L
1
31
40435682
Blade Fuse Holder
1
32
40435683
Blade Fuse, 7.5A, 19.1x5.1x18.5
1
33
40435684
Electric plug connector
1
34
40421915
Strap, L=300mm
10
