Oil gauge
(2) Checking Transmission oil
If it is within the deviant line of oil gauge, it is
‘proper level’.
When checking, stop the engine.
For adding oil, refer to capacity table.
Oil gauge
H
L
▶
Before checking the oil level, park the tractor on the level ground.
▶
If oil is polluted, it may cause the early wearing of machine and the failure of
hydraulic system. Clean around oil injection inlet clear the cap.
Warning
(3) Checking Front axle oil
capacity
Open the plug of checking inlet and check if there
is oil leakage.
If insufficient, pour the oil into injection inlet.
(check the state by using the checking inlet 5~10
minutes later after injecting.)
For adding oil, refer to “Lubricants and Capacity
table” (See page 5-3).
Normal capacity : 10ℓ (2.6gal)
Injection inlet
Checking outlet
5
5 5
5 - 13
(4) Battery check
Refer to “Batter handling and Notices” (See page 5-25)
(5) Air cleaner (Dry type)
(See page 5-9)
(6) Cleaning Radiator and Radiator screen
(See page 5-10)
