LSIS SV008iC5-1F User Manual

7. Function List
7-9
LED
display
Parameter
name
Min/Max
range
Description
Factory
defaults
Adjustable
during run
Page
H14 [Skip
frequency
high limit 2]
25.0 X
H15
[Skip
frequency
low limit 3]
30.0
X
H16 [Skip
frequency
high limit 3]
35.0 X
H17
S-Curve
accel/decel
start side
1/100
[%]

Set the speed
reference value to form a
curve at the start during
accel/decel. If it is set
higher, linear zone gets
smaller.
40
X
H18 S-Curve
accel/decel
end side
1/100
[%]
 Set the speed
reference value to form a
curve at the end during
accel/decel. If it is set
higher, linear zone gets
smaller.
40 X
H19
[Output
phase loss
protection
select]
0/1

Inverter turns off the
output when the phase of
the inverter output (U, V,
W) is not properly
connected.
0
O
H20 [Power On
Start select]
0/1  This parameter is
activated when drv is set to
1 or 2 (Run/Stop via
Control terminal).
 Motor starts
acceleration after AC power
is applied while FX or RX
terminal is ON.
0 O
H21
[Restart
after fault
reset]
0/1

This parameter is
active when drv is set to 1
or 2 (Run/Stop via Control
terminal).
 Motor accelerates after
the fault condition is reset
while the FX or RX
terminal is ON.
0
O
1) Set H10 to 1 to be displayed.
# H17, 18 is used when F2, F3 is set to 1 S-Curve.
