LSIS SV008iC5-1F User Manual

9. Specifications
9-1
9. Specifications
9.1 Technical Data
 Input and output ratings
Model : SV xxx iC5 – 2x
004
008
015
022
Max motor
capacity
1
[HP] 0.5 1 2 3
[kW]
0.4
0.75
1.5
2.2
Output
ratings
Capacity
[kVA]
2
0.95 1.9 3.0 4.5
FLA [A]
2.5
5
8
12
Frequency 0 ~ 400 [Hz]
3
Voltage
Three Phase 200 ~ 230V
4
Input
ratings
Voltage Single Phase 200 ~ 230V (±10%)
Frequency
50 ~ 60 [Hz] (
±
5%)
Current 5.5 9.2 16 21.6
 Control
Control mode V/F control, Sensorless vector control
Frequency setting
resolution
Digital: 0.01Hz
Analog: 0.06Hz (Max. frequency : 60Hz)
Accuracy of Frequency
command
Digital: 0.01% of Max. output frequency
Analog: 0.1% of Max. output frequency
V/F Ratio
Linear, Squared Pattern, User V/F
Overload capacity Software: 150% for 60 s
Torque boost
Auto/Manual torque boost
 Operation
Operation mode
Keypad/ Terminal/ Communication option selectable
Frequency setting
Analog: 0 ~ 10[V], 0 ~ 20[mA], Keypad Potentiometer
Digital : Keypad
Operation features
PID control, Up-Down operation, 3-wire operation
Input
Multi-function
terminal
NPN/ PNP selectable
Function: (refer to page 3-5)
1
Indicates the maximum applicable motor capacity when using a 4-pole standard motor.
2
Rated capacity is based on 220V.
3
Max. settable freq is 300Hz when H30 is set to 3 “Sensorless Vector Control”.
4
Max. output voltage will not be greater than the input voltage. Output voltage less than the input voltage
can be programmed.
