Registers
Auxiliary mA Input Configuration Continued
4524 Get/Set Channel 1 20mA Input FLOAT 20mA Input Value Value depends upon
channel range
5114 Channel 2
5704 Channel 3
4526 Get/Set Channel 1 Input Filter INT Input Filter 1050 = Filter Out
5116 Channel 2 1051 = 10 Seconds
5706 Channel 3 1052 = 20 Seconds
1053 = 40 Seconds
1054 = 1 Minutes
1055 = 3 Minutes
1056 = 5 Minutes
4527 Get/Set Channel 1 First Label INT 1
st
Character of Channel
Description Label
Refer To Table 1
5117 Channel 2
5707 Channel 3
4528 Get/Set Channel 1 Second Label INT 2
nd
Character of Channel
Description Label
5118 Channel 2
5708 Channel 3
4529 Get/Set Channel 1 Third Label INT 3
rd
Character of Channel
Description Label
5119 Channel 2
5709 Channel 3
4530 Get/Set Channel 1 Fourth Label INT 4
th
Character of Channel
Description Label
5120 Channel 2
5710 Channel 3
4531 Get/Set Channel 1 Fifth Label INT 5
th
Character of
Description Label
5121 Channel 2
5711 Channel 3
4532 Get/Set Channel 1 Sixth Label INT 6
th
Character of
Description Label
5122 Channel 2
5712 Channel 3
4533 Get/Set Channel 1 Seventh Label INT 7
th
Character of
Description Label
5123 Channel 2
5713 Channel 3
4534 Get/Set Channel 1 Eighth Label INT 8
th
Character of
Description Label
5124 Channel 2
5714 Channel 3
4535 Get/Set Channel 1 Ninth Label INT 9
th
Character of
Description Label
5125 Channel 2
5715 Channel 3
4536 Get/Set Channel 1 Tenth Label INT 10
th
Character of
Description Label
5126 Channel 2
5716 Channel 3
4537 Get/Set Channel 1 Eleventh Label INT 11
th
Character of
Description Label
5127 Channel 2
5717 Channel 3
4538 Get/Set Channel 1 Twelfth Label INT 12
th
Character of
Description Label
5128 Channel 2
5718 Channel 3
4539 Get/Set Channel 1 Thirteenth
Label
INT 13
th
Character of
Description Label
5129 Channel 2
5719 Channel 3
To Next Page
