LTH Electronics MXD70 Series User Manual

Registers
Modbus RS485 Interface
Operating Guide
- 31 -
Registers
Auxiliary mA Input Configuration Continued
4540 Get/Set Channel 1 Fourteenth
Label
INT 14
th
Character of
Description Label
Refer To Table 1
5130 Channel 2
5720 Channel 3
4541 Get/Set Channel 1 Fifteenth Label INT 15
th
Character of
Description Label
5131 Channel 2
5721 Channel 3
7700 Get/Set Channel 1 Custom Curve A
points
INT Number of Custom
Curve A points
*(Not Available when
input mode set to
4-20mA or 0-20mA)
2 to 10
7790 Channel 2
7880 Channel 3
7701 Get/Set Channel 1 Curve A mA
Input Point 1
FLOAT Curve A mA Input Value
Point 1
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7791 Channel 2
7881 Channel 3
7703 Get/Set Channel 1 Curve A
Auxiliary mA
Input Point 1
FLOAT Curve A Auxiliary mA
Input Value Point 1
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7793 Channel 2
7883 Channel 3
7705 Get/Set Channel 1 Curve A mA
Input Value
Point 2
FLOAT Curve A mA Input Value
Point 2
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7795 Channel 2
7885 Channel 3
7707 Get/Set Channel 1 Curve A
Auxiliary mA
Input Point 2
FLOAT Curve A Auxiliary mA
Input Value Point 2
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7797 Channel 2
7887 Channel 3
7709 Get/Set Channel 1 Curve A mA
Input Point 3
FLOAT Curve A mA Input Value
Point 3
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7799 Channel 2
7889 Channel 3
7711 Get/Set Channel 1 Curve A
Auxiliary mA
Input Value
Point 3
FLOAT Curve A Auxiliary mA
Input Value Point 3
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7801 Channel 2
7891 Channel 3
7713 Get/Set Channel 1 Curve A mA
Input Value
Point 4
FLOAT Curve A mA Input Value
Point 4
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7803 Channel 2
7893 Channel 3
7715 Get/Set Channel 1 Curve A
Auxiliary mA
Input Value
Point 4
FLOAT Curve A Auxiliary mA
Input Value Point 4
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7805 Channel 2
7895 Channel 3
