Registers
- 32 -
Modbus RS485 Interface
Operating Guide
Registers
Auxiliary mA Input Configuration Continued
7717 Get/Set Channel 1 Curve A mA
Input Value
Point 5
FLOAT Curve A mA Input Value
Point 5
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7807 Channel 2
7897 Channel 3
7719 Get/Set Channel 1 Curve A
Auxiliary Point
5
FLOAT Curve A Auxiliary mA
Input Value Point 5
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7809 Channel 2
7899 Channel 3
7721 Get/Set Channel 1 Curve A mA
Input Point 6
FLOAT Curve A mA Input Value
Point 6
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7811 Channel 2
7901 Channel 3
7723 Get/Set Channel 1 Curve A
Auxiliary Point
6
FLOAT Curve A Auxiliary mA
Input Value Point 6
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7813 Channel 2
7903 Channel 3
7725 Get/Set Channel 1 Curve A mA
Input Point 7
FLOAT Curve A mA Input Value
Point 7
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7815 Channel 2
7905 Channel 3
7727 Get/Set Channel 1 Curve A
Auxiliary Point
7
FLOAT Curve A Auxiliary mA
Input Value Point 7
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7817 Channel 2
7907 Channel 3
7729 Get/Set Channel 1 Curve A mA
Input Point 8
FLOAT Curve A mA Input Value
Point 8
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7819 Channel 2
7909 Channel 3
7731 Get/Set Channel 1 Curve A
Auxiliary Point
8
FLOAT Curve A Auxiliary mA
Input Value Point 8
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7821 Channel 2
7911 Channel 3
7733 Get/Set Channel 1 Curve A mA
Input Point 9
FLOAT Curve A mA Input Value
Point 9
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7823 Channel 2
7913 Channel 3
7735 Get/Set Channel 1 Curve A
Auxiliary Point
9
FLOAT Curve A Auxiliary mA
Input Value Point 9
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7825 Channel 2
7915 Channel 3
