LTH Electronics MXD70 Series User Manual

Registers
Modbus RS485 Interface
Operating Guide
- 33 -
Registers
Auxiliary mA Input Configuration Continued
7737 Get/Set Channel 1 Curve A mA
Input Point 10
FLOAT Curve A mA Input Value
Point 10
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7827 Channel 2
7917 Channel 3
7739 Get/Set Channel 1 Curve A
Auxiliary Point
10
FLOAT Curve A Auxiliary mA
Input Value Point 10
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7829 Channel 2
7919 Channel 3
7741 Get/Set Channel 1 Custom Curve B
points
INT Number of Custom
Curve B points
*(Not Available when
input mode set to
4-20mA or 0-20mA)
2 to 10
7831 Channel 2
7921 Channel 3
7742 Get/Set Channel 1 Curve B mA
Input Point 1
FLOAT Curve B mA Input Value
Point 1
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7832 Channel 2
7922 Channel 3
7744 Get/Set Channel 1 Curve B
Auxiliary Point
1
FLOAT Curve B Auxiliary mA
Input Value Point 1
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7834 Channel 2
7924 Channel 3
7746 Get/Set Channel 1 Curve B mA
Input Point 2
FLOAT Curve B mA Input Value
Point 2
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7836 Channel 2
7926 Channel 3
7748 Get/Set Channel 1 Curve B
Auxiliary Point
2
FLOAT Curve B Auxiliary mA
Input Value Point 2
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7838 Channel 2
7928 Channel 3
7750 Get/Set Channel 1 Curve B mA
Input Point 3
FLOAT Curve B mA Input Value
Point 3
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7840 Channel 2
7930 Channel 3
7752 Get/Set Channel 1 Curve B
Auxiliary Point
3
FLOAT Curve B Auxiliary mA
Input Value Point 3
*(Not Available when
input mode set to
4-20mA or 0-20mA)
Value depends upon
channel range
7842 Channel 2
7932 Channel 3
7754 Get/Set Channel 1 Curve B mA
Input Point 4
FLOAT Curve B mA Input Value
Point 4
*(Not Available when
input mode set to
4-20mA or 0-20mA)
0 to 20.00ma
7844 Channel 2
7934 Channel 3
